4-axis production turning with 2 turrets and counter spindle as standard

Turn & Mill Overview The turn-mill machines of the CTX TC, NT and NTX series represent the premium class of universal turning centres. Up to 6-side turning and up to 5-axis CNC milling can be achieved in one setting with these turning machines. DMG CTX Beta 1250TC Mill Turn Sign in to follow this. DMG CTX Beta 1250TC Mill Turn. By Mcam Nut, August 5, 2010 in Industrial Forum. Recommended Posts.

  • Two 12-fold VDI 40 star turrets with 4,000 rpm, 15.2 hp and 20.7 ft lb
  • Optional Direct Drive turret with 10,000 rpm and TRIFIX precision quick-change system for highest accuracy
  • Main and counter spindle with 5,000 rpm, 64.4 hp and 265.5 ft lb

Dmg 1250 Ctx Mill Turncleverbridal For Sale

Patented TWIN concept for parallel processing with 2 tool carriers

  • Optimal work space utilization by working space concept with two turrets and cross stroke* of the counter-spindle tailstock combination *
  • Y-axis on both turrets (up ± 2.4 in, down * ± 1.6 in) for the complete machining of bars, shafts and chuck parts
  • Rotating diameter up to 13.4 in at 47.2 in turning length
TurncleverbridalDmg 1250 Ctx Mill Turncleverbridal

Maximum productivity thanks to parallel processing with a second tool carrier

TurncleverbridalMill
  • Second tool carrier as a turret with 12 or 16 driven stations (VDI40 / VDI30)
  • Turret as DirectDrive with 10,000 rpm and 80 mm Y-stroke
  • Ideal for serial production through optional automation solutions, Integrated handling system or portal loading
  • Optional with complete package for bar machining with automatic workpiece pickup device

Complex turning and milling operations with ultra-compact turning/milling spindle and up to 20,000 rpm

Dmg Ctx 1250

  • Turning and milling spindle compactMASTER with 12,000 rpm, 22 kW and 120 Nm. As high-speed version with 20,000 rpm
  • ± 100 mm Y-stroke for external machinings
  • Swivel range of the B axis ± 110 ° for maximum flexibility

Dmg 1250 Ctx Mill Turncleverbridal Ctr

Large machining compartment for workpieces up to Ø 500 x 1,185 mm

Dmg 1250 Ctx Mill Turncleverbridal Parts

  • Circular diameter up to 500 mm
  • Bore or turn 400 mm long workpieces horizontally
  • 470 mm outer diameter with vertical position of the B-axis (with 70 mm tool length)
